Product Dimensions 33.88"h x 60"w x 33.25"d
The UF48B-D4 Steelheart Series Undercounter two section freezer with stainless drawers is a space saving workhorse. Engineered to maintain food safe temperatures in 100°F ambient conditions with a net capacity of 12 cubic feet this efficient undercounter freezer and front air flow design is perfect for hot/tight kitchens.Read More
or
Innovative air distribution system distributes air evenly to maintain product temperature
Enamel coated evaporator coil for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
Field reversible, spring assisted self closing doors with stay open feature (no kit req’d)
Extruded aluminum flush mount door handles
(2) stainless steel doors with ABS interior liner
Insulated with 2″ CFC free, foamed in place polyurethane
(4) epoxy coated wire shelves adjustable in 1/2″ increments on anodized aluminum supports
Engineered to maintain food safe temperatures in 100°F ambient conditions
R290 refrigerant
(4) 4″ Stem Casters (2 with brakes) are standard
Nominal Compres. of 2870 BTU/hr at 1/2+ HP
115v/60/1, 10 ft. cord and plug
Optional Kits: 2″ or 6″ casters, overshelves (single or double), epoxy wire shelf, stainless steel shelf, foot pedal kit (left or right hinge), see spec sheet for additional options
General Specs | |
| Width (in.) | 60 |
| Depth (in.) | 33.25 |
| Height (in.) | 33.88 |
| Defrost System | Automatic |
| Manufacturer Warranty | 7 Years Labor, Parts and Compressor |
| Color | Stainless Steel |
| Depth w/Door Open 90 Degrees (in.) | 54.75 |
| Installation Type | Freestanding |
| Door Color | Stainless Steel |
| Depth Type | Counter Depth |
| Overall Height (in.) | 33.88 |
| Door Panel Type | Solid |
| Garage Ready | No |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Ice Maker | No |
| Smart Compatible | No |
| Shipping Depth (in.) | 35.75 |
| Shipping Width (in.) | 63.75 |
| Shipping Height (in.) | 36 |
| Voltage | 104-126 |
| Amp | 5 |
Other Dimensions | |
| Voltage | 115/60/1 |
| HACR Breaker | 15.0 Amps |
| Electrical Connection (NEMA) | 5-15P |
| Ambient Temperature Range | 45° to 100°F |
| Control Setpoint Range | -10° to 10°F |
| Energy Consumption (kWh/day) @NSF | 4.5 |
| Heat Rejection (BTU/Hr.) @NSF | 786 |
| Approximate Nominal Compres. BTU/HR (HP) | 2870 (1/2+HP) |
| Refrigerant / Charge Amount (oz) | R290 (2.8 oz) |
| Interior Storage Capacity (CF) (AHAM) | 17.22 ft3 |
| Door Opening Width x Height | 19.5” x 23” |
| Recommended Setpoint | 2°F |
| Shelf Dimensions (W x D) | 21.5” x 25.5” |
